Container Terminal


Johor Port's Container Terminal is constantly improving its services and increasing options for logistics and connectivity. It is a dedicated terminal servicing major shipping lines calling the port regularly with latest capacity of 1.45 million TEUs at one time.

The terminal utilizing 9 quay cranes, 30 rubber-tyred gantry cranes, 6 reach stackers (40-tonnes capacity), 5 front end loaders (FELs) for empty containers, and 62 prime movers to facilitate efficient terminal services with ample container yard area of 291,150 sq.m.

Optimal commercial operational efficiency is certain by capitalizing state-of-the-art Web-based Johor Port Container Terminal System (JCTS) with real-time, integrated, paperless transactions. Dedicated rail depot within terminal to connect to the nationwide rail network will ensure efficient logistics solution.

9,600 sq.m Container Freight Station (CFS) facilitates adjacent to the Container Yard provide cost-effective stuffing and unstuffing, LCL cargo consolidation, and temporary storage of Breakbulk cargo.


Container Terminal Container Handling Equipment Storage Facilities
Number of Berth 3 Prime Mover
  • 60 t (Max. Towed Load including CT)
 62 Container Freight Station 9,600 sq.m
Total Quay Length 0.73 km Quay Crane
  • 40.6 t
  • 16 row
 9 Total Annual Yard Capacity 1.45 mil. TEUs
Controlling Depth in Channel 12.5 m Reach Stacker
  • 40 t
 6 Reefer Points 216
Front End Loaders for Empty 5

WHARVES AND JETTIES INFORMATION AS AT 19th FEBRUARY 2024
(based on survey done on 16 February 2024)
BERTH LENGTH WHARF MARK BERTH DEPTH BERTH DRAFT DWT DISPLACEMENT
CONTAINER
CT1 236M 00-236 13.5M 13.0M 80 K 104 K
CT2 236M 236-473 13.5M 13.0M 80 K 104 K
CT3 236M 473-710 13.5M 13.0M 80 K 104 K
MOORING BUOY     6.5M 6.0M
IDEMITSU     8.7M 8.2M   CONTROLLING
DEPTH 7.70M
UPDATED FEBRUARY 2022
